Fuel Injectors
Size Cost + Shipping
14lb/hr to 24lb/hr 29.95ea.
26lb/hr 32.95
30lb/hr 34.95
32lb/hr 38.95
36lb/hr 53.95
40lb/hr 58.95
48lb/hr 68.95
55lb/hr 86.95
72lb/hr 89.95
83lb/hr 92.95
Honda / Acura injectors
size cost + shipping
195cc/255cc/ 370cc low Imp. $63.95 ea.
195cc/255cc/260cc/310cc high Imp. $63.95 ea.
How to properly estimate the engines fuel requirements ( Injector Size ).
A good estimate is that every 100 HP needs 50LB/Hr (8.0 US gal/hr. of fuel.
Example: You have a 6 Cylinder engine that is expected to make 375HP
You do not want to exceed 85% dutycycle firing time. So we suggest you
multiply you expected output by 1.2 to compensate for this factor and insure
you dont buy to small of a injector.
higher RPM engines, generally over 6500RPM may need larger injectors due to
shorter available firing times at higher RPM.
